Syringe Pumps – LP Series

TJ-3A Single-channel Syringe Pump provides both infusion and withdrawal capabilities, allowing for flexible experimental setups. It is compatible with syringes ranging from 10 μL to 60 mL, making it ideal for precise control of low flow rates. This pump is suitable for use with the AIO / AIO-SPE cell, Flow-cell add-ons, and printed and thin-film electrodes, offering reliability and adaptability for various laboratory applications.

• Dimensions: 170 x 108 x 70 mm / 245 x 100 x 95 mm (control unit / drive unit) (L x W x H)
• Operating mode: Infusion, withdrawal, infusion/withdrawal, withdrawal/infusion, continuous
• Channels: 1
• Advance per step: 0.165 µm
• Linear force: > 90 N
• Accuracy: ≤ ± 0.5% error in the condition > 30% of the maximum infusion distance
• Flow rate range: 0.139 µL/min – 52.9 mL/min
• Syringe size: 1 – 60 mL
• Communication interface: RS485
• Pump stroke: 90 mm
• Maximum linear speed: 79.4 mm/min
• Minimum linear speed: 7.9 µm/min
• State signal output: 2 output signals (OC gate signal) to indicate start/stop and direction
• Control signal input: Falling edge signal or TLL to control start/stop
• Display: Shows volume, flow rate, or linear speed (128×64 graphic LCD)
• Power-off memory: Storing the running parameters automatically
• Power supply: AC 90V-260V / 10W
• Operating temperature: 0 to 40 ºC
• Humidity: < 80%
• Weight: 0.8 Kg (control unit), 1.3 Kg (drive unit)
• Certifications: CE

LSP02-2B Dual-channel Syringe Pump offers both infusion and withdrawal functions, providing flexibility for complex experiments. It supports syringes from 10 µL to 140 mL, making it ideal for precise control of low flow rates. This dual-channel system is suitable for use with the AIO / AIO-SPE cell, Flow-cell add-ons, and printed and thin-film electrodes, ensuring versatility across a range of applications.

• Dimensions: 280 x 250 x 140 mm (L x W x H)
• Operating mode: Infusion, withdrawal, infusion/withdrawal, withdrawal/infusion, continuous
• Channels: 2
• Advance per step: 0.156 µm
• Linear force: > 180 N
• Accuracy: ≤ ± 0.5% error in the condition > 30% of the maximum infusion distance
• Flow rate range: 0.83 nL/min – 150.5 mL/min
• Syringe size: 10 µL – 140 mL
• Communication interface: RS485
• Pump stroke: 140 mm
• Maximum linear speed: 130 mm/min
• Minimum linear speed: 5 µm/min
• State signal output: 2 output signals (OC gate signal) to indicate start/stop and direction
• Control signal input: Falling edge signal or TLL to control start/stop
• Display: Shows volume, flow rate, or linear speed (128×64 graphic LCD)
• Power-off memory: Storing the running parameters automatically
• Power supply: AC 90V-260V / 20W
• Operating temperature: 0 to 40 ºC
• Humidity: < 80%
• Weight: 4.3 Kg
• Certifications: CE, EMC, ESD ≥ Level IV (IEC 61000-4-2)

LSP01-2A Single-channel Syringe Pump is designed for precise infusion with an impressive accuracy of up to 1 µm/min. It is compatible with syringes ranging from 10 μL to 60 mL, making it suitable for applications that demand high precision and control. This pump is compatible with the AIO / AIO-SPE cell, Flow-cell add-ons, as well as printed and thin-film electrodes, offering flexibility for various experimental setups.

• Dimensions: 280 x 210 x 140 mm (L x W x H)
• Operating mode: Infusion
• Channels: 1
• Advance per step: 0.031 µm
• Linear force: > 90 N
• Accuracy: ≤ ± 0.5% error in the condition > 30% of the maximum infusion distance
• Flow rate range: 0.16 nL/min – 10.8 mL/min
• Syringe size: 10 µL – 60 mL
• Communication interface: RS485
• Pump stroke: 140 mm
• Maximum linear speed: 13 mm/min
• Minimum linear speed: 1 µm/min
• State signal output: 2 output signals (OC gate signal) to indicate start/stop and direction
• Control signal input: Falling edge signal or TLL to control start/stop
• Display: Shows volume, flow rate, or linear speed (128×64 graphic LCD)
• Power-off memory: Storing the running parameters automatically
• Power supply: AC 90V-260V / 15W
• Operating temperature: 0 to 40 ºC
• Humidity: < 80%
• Weight: 3.6 Kg
• Certifications: CE

LSP01-3A Single-channel Syringe Pump is designed for precise infusion with an accuracy of up to 5 µm/min. It is compatible with syringes ranging from 10 μL to 60 mL, making it an excellent choice for applications requiring high precision. This model is compatible with the AIO / AIO-SPE cell, Flow-cell add-ons, as well as printed and thin-film electrodes, providing versatility in various experimental setups

• Dimensions: 280 x 210 x 140 mm (L x W x H)
• Operating mode: Infusion
• Channels: 1
• Advance per step: 0.156 µm
• Linear force: > 90 N
• Accuracy: ≤ ± 0.5% error in the condition of > 30% of the maximum infusion distance
• Flow rate range: 0.83 nL/min – 54.2 mL/min
• Syringe size: 10 µL – 60 mL
• Communication interface: RS485
• Pump stroke: 140 mm
• Maximum linear speed: 65 mm/min
• Minimum linear speed: 5 µm/min
• State signal output: 2 output signals (OC gate signal) to indicate start/stop and direction
• Control signal input: Falling edge signal or TLL to control start/stop
• Display: Shows volume, flow rate, or linear speed (128×64 graphic LCD)
• Power-off memory: Storing the running parameters automatically
• Power supply: AC 90V-260V / 15W
• Operating temperature: 0 to 40 ºC
• Humidity: < 80%
• Weight: 3.6 Kg
• Certifications: CE, EMC, ESD ≥ Level IV (IEC 61000-4-2)

dLSP-520 Digital Lab Dual-Syringe Pump offers high-precision and stable fluid control with both infusion and withdrawal functions. It is ideal for applications requiring meticulous fluid management, such as microfluidics, electrospinning, toxicology studies, capillary electrophoresis, drug discovery, cell injections, microcapsule production, catalyst research, neuroscience, organic synthesis, and nutrition science. This dual-syringe setup enhances flexibility and precision for complex laboratory workflows.

• Dimensions: Drive unit: 260 mm x 185 mm x 180 mm (L x W x H), Control unit: 190 mm x 123 mm x 33 mm (L x W x H)
• Operating mode: Infusion, withdrawal, infusion/withdrawal, autorepeat, programming (on dedicated PC software)
• Channels: 2
• Motor type: Step motor
• Microstepping: 1/64
• Advance per step: 0.03255 µm/µstep
• Maximum speed: 180 mm/min
• Minimum speed: 0.0833 µm/min
• Linear force: 40 lbs/18 kg (100% force selection)
• Accuracy: ≤± 0.5%
• Flow rate range: 0.0007 nL/min (0.5 µL syringe) – 74.786 mL/min (30 mL syringe)
• Syringe size: 0.5 µL – 30 mL
• Communication interface: USB-B, USB-A, Wi-Fi, Bluetooth, Ethernet, etc.
• Display: 7-inch, 1024×600, IPS HD LCD
• Power supply: AC 100V-240V/30 W 50/60Hz
• Operating temperature: 5 ºC – 40 ºC
• Humidity: < 85%
• Weight: 3.49 kg (drive unit), 0.37 kg (controller)
• IP rating: IP31
• Certifications: CE

dLSP510 Digital lab single-syringe pump delivers high-precision and stable fluid control, making it an ideal choice for a wide range of advanced applications including microfluidics, electrospinning, toxicology studies, capillary electrophoresis, drug discovery, cell injections, microcapsules, catalyst research, neuroscience, organic synthesis, and nutrition science. This digital pump is designed to support intricate lab processes that require consistent and precise fluid delivery.

• Dimensions: 260 x 185 x 180 mm (L x W x H) drive unit, 190 x 123 x 33 mm (L x W x H) controller unit
• Operating mode: Infusion, withdrawal, infusion/withdrawal, autorepeated, programming (on dedicated PC software)
• Channels: 1
• Motor type: Step motor
• Microstepping: 1/64
• Advance per step: 0.03255 µm / µstep
• Maximum speed: 180 mm/min
• Minimum speed: 0.0833 µm/min
• Linear force: 40 lbs/18 kg (100% force selection)
• Accuracy: ≤± 0.5%
• Flow rate range: 0.0007 nL/min (0.5 µL syringe) – 120.044 mL/min (60 mL syringe)
• Syringe size: 0.5 µL – 60 mL
• Communication interface: USB-B, USB-A, Wi-Fi, Bluetooth, Ethernet, etc.
• Display: 7-inch, 1024×600, IPS HD LCD
• Power supply: AC 100 V – 240 V-30 W 50/60 Hz
• Operating temperature: 5 ºC – 40 ºC
• Humidity: < 85%
• Weight: 3.49 kg (drive unit), 0.37 kg (controller)
• IP rating: IP31
• Certifications: CE
